Blue-Robe Submersible Pump

Blue-Robe Submersible Pump

Characteristic
It can be one pump for multiple nozzles for the larger amount of refueling and the faster speed of refueling to reduce the queuing time.
It can be several fuel dispensers shared from the tank by one inlet pipe which won’t cause mutual influence or uneven flow. When one pump stops there won’t be the possibility of suction the air or even cutoff the flow. This process greatly simplifies the pipeline and makes the layout of the stations more flexible.
It can prevent gas resistance by the positive pressure won’t make the tank diameter larger tubing longer or pipe bend more; a lot of using the high octane fuel unleaded gasoline; the station built in the high altitude area; average temperature increased; all the influence of factors above to ensure the normal operation of the stations.

Product catalogue (Instruction manual)
Download

Technical Specification
Type Power
HP
Voltage
V
Flow Rate
L/m
Outlet Pressure
KPa
Working Qty.
of Nozzles
QYB75 0.75 220/380 228 207 4
QYB150 1.5 220/380 304 207 6
QYB200 2 220/380 380 276 8
QYB300 3 380 600 276 12
QYB500 5 380 1000 276 16
