Unloading Flowmeter
Unloading Flowmeter is mainly used for the measuring of gravity self-flow unloading of tanker in gas station and can be used for measurement of a variety of oil products except water. Simple and flexible installation simple operation accurate measurement and long service life etc.
Characteristic
High accuracy High reliability.
Easy to Use
Safe and Reliable Measurement Data
Safe and Reliable Equipment
Product catalogue (Instruction manual)
Download| Technical Specification | |||
| Model | FA-1 | Flow Rate | 8-80m³/h（130-1300L/min）(34-340gal/min) |
| Pipe Diameter | 3"（DN80） | Min. Scale | 1L(0.264gal) |
| Accuracy | ±0.1% | Ex Grade | Ex ia Ⅱ BT4 Ga |
| Repeatability Accuracy | ±0.02% | Protection Grade | IP67 |
| Weight | 6KG | Temp. | -25℃-+55℃ |
| Material | Aluminum | Max. Pressure | 0.5MPA |
| LCD Screen | English Version, 7 Digit Display,Interfaz en espanol, visualizacionde 7 digitos | Oil Viscosity Range | ≤13m㎡/s |
| Applicable Medium | Gasoline, Diesel, Kerosene, Ethanol Gasoline, and other Oil products | Power Supply |
A rechargeable lithium battery
|
